Monitoring

The Operator Service supports monitoring using Prometheus by providing a /metrics endpoint that Prometheus can scrape to gather various metrics about your validator operations.

IconPrerequisites
  • Operator application running and accessible
  • Prometheus server installed and running
  • Basic knowledge of how to configure Prometheus targets
  • Grafana Dashboard ↗ for v3-operator ↗ installed

Setup Operator for Monitoring

The Operator provides flexibility to define the host and port for the metrics endpoint via environment variables:

IconEnvironment Variables

ENABLE_METRICS - Defines whether the metrics endpoint should be enabled (default: false)

METRICS_HOST - Defines the hostname or IP on which the metrics endpoint will be available

METRICS_PORT - Defines the port on which the metrics endpoint will be available

Ensure that these environment variables are set as per your requirements.

IconEnvironment Variables Example
export ENABLE_METRICS=true
export METRICS_HOST=0.0.0.0
export METRICS_PORT=9100
IconCommand-Line Flags

You can also specify them by providing --enable-metrics, --metrics-port and --metrics-host flags to the start command.

The Operator Service's metrics will be available at http://[METRICS_HOST]:[METRICS_PORT]/metrics.

Configure Prometheus

To monitor the Operator, configure Prometheus to scrape metrics from the exposed /metrics endpoint.

Add the following job configuration to your Prometheus configuration file (prometheus.yml):

scrape_configs:
- job_name: 'operator'
scrape_interval: 30s
static_configs:
- targets: ['<METRICS_HOST>:<METRICS_PORT>']

Replace <METRICS_HOST> and <METRICS_PORT> with the values you've configured in the Operator.

This configuration tells Prometheus to scrape metrics from the Operator every 30 seconds.
